Crusher Banking Compound Bangalore Suppliers

Looking for crusher backing compound manufacturers in Bangalore? Explore crusher backing compound specifications, applications, benefits, suppliers, and FAQs for mining, quarrying, cone and gyratory crushers. 10-10-2026

Crusher Banking Compound

Crusher Banking Compound Crusher Banking Compound

. Blog
2500/- + 18% TAX [GST] Call Now

Crusher Banking Compound Spec.

Looking for a reliable Crusher Backing Compound Manufacturer in Bangalore? Crusher backing compounds are two-component epoxy systems designed to provide strong, durable support between crusher liners and crusher bodies. They help absorb vibration, fill gaps, and provide mechanical support during heavy-duty crushing operations.

Technical Specifications

SpecificationTypical / Available Specification*
Product type Two-component epoxy backing compound
Base Epoxy resin + hardener
Appearance Liquid / viscous liquid before curing
Compressive strength Approx. 60–100+ MPa, depending on grade
Mixing ratio Formulation-dependent; examples include 100:4, 100:10 and 2:1
Pot life Approx. 20–40 minutes for some grades
Full cure Approx. 6–24 hours, depending on formulation and temperature
Application Pouring / casting behind crusher liners
Temperature resistance Formulation-dependent
Main properties Impact resistance, vibration resistance, high compressive strength, low shrinkage
Packaging Commonly 10 kg

Enquire Us Buy Now

Products Details

*Review .Store Location

Crusher Banking Compound Details and Uses

crusher backing compound manufacturers in Bangalore, crusher backing compound Bangalore, crusher backing compound suppliers Bangalore, epoxy crusher backing compound, cone crusher backing compound, gyratory crusher backing compound, crusher liner backing compound, mining crusher backing compound By Unnathi Suppliers

Crusher Backing Compound Manufacturers in Bangalore

Crusher Backing Compound is generally formulated as an epoxy resin and hardener system. After mixing, the material is poured behind wear liners to create a solid backing layer. Depending on the formulation, products available in the Bangalore market can offer high compressive strength, impact resistance, low shrinkage and resistance to vibration and abrasion.

The compound is commonly supplied as a two-component kit and is suitable for maintenance and liner installation in cone, gyratory, jaw and impact crusher applications, depending on the specific product formulation.

*Specifications vary substantially between manufacturers and grades, so the manufacturer's technical datasheet should be used for final selection. Published Bangalore-area specifications include 80 MPa compressive strength and 20–30 minute pot life for one product, while another lists >100 MPa compressive strength.

Where Is Crusher Backing Compound Used?

1. Cone Crushers

Used between the crusher body and wear liners to provide uniform support and help absorb operational impact and vibration.

Suitable for backing and supporting liners in large gyratory crushing equipment used in mining and aggregate operations.

3. Primary Crushers

Heavy-duty backing compounds can be used with primary crushing equipment where liners experience substantial impact and compressive loads.

4. Mining & Quarrying

Crusher backing compounds are used in mining, quarrying and aggregate-processing plants to support crusher wear components and facilitate maintenance.

5. Crusher Maintenance & Liner Replacement

The compound fills the space behind liners, helping create continuous support and reducing unwanted movement during operation.

6. Machinery Grouting

Some epoxy backing formulations can also be used for machinery grouting, base-plate support and related industrial maintenance applications.

Benefits of Crusher Backing Compound

  • High compressive strength
  • Good impact and vibration resistance
  • Low-shrinkage formulations available
  • Supports crusher wear liners
  • Helps fill gaps between liner and crusher body
  • Suitable for heavy-duty mining and quarrying environments
  • Pourable formulations simplify installation
  • Can reduce maintenance-related downtime when correctly applied

Why Source Crusher Backing Compound from Bangalore?

Bangalore is a major industrial and engineering market with access to manufacturers, chemical suppliers, mining-equipment suppliers and maintenance-service providers. Local sourcing can make it easier to obtain technical assistance, bulk quantities and delivery support for industrial maintenance requirements.

Frequently Asked Questions

What is crusher backing compound?

Crusher backing compound is typically a two-component epoxy material used behind crusher wear liners. It provides mechanical support and helps absorb impact and vibration during crushing operations.

Which crushers use backing compound?

Depending on the product specification, backing compounds are used with cone, gyratory, primary, jaw and impact crushers. Always verify compatibility with the particular crusher and liner system.

What is the mixing ratio?

There is no single universal ratio. Published products include ratios such as 100:4, 100:10 and 2:1 by weight. The exact manufacturer's technical datasheet should always be followed.

How long does crusher backing compound take to cure?

Curing varies by formulation and temperature. Published products indicate anything from approximately 6 hours to 24 hours for full/hard cure.

Is crusher backing compound suitable for mining applications?

Yes. Epoxy crusher backing compounds are specifically marketed for heavy-duty mining, quarrying and aggregate crushing applications, particularly for cone and gyratory crushers.

How should crusher backing compound be applied?

Typically, the liner and surrounding metal surfaces are cleaned and prepared, the resin and hardener are mixed according to the manufacturer's specified ratio, and the compound is poured into the required cavity behind the liner. Surface preparation and application procedures should follow the product technical datasheet.

What packaging sizes are available?

Depending on the manufacturer, crusher backing compounds are available in 10 kg, 20 kg, 25 kg, 50 kg and custom industrial pack sizes.

Where can I buy crusher backing compound in Bangalore?

Crusher backing compound is available through industrial epoxy manufacturers and suppliers in areas of Bengaluru such as Banashankari and other industrial/commercial locations. Buyers should compare the technical datasheet and crusher compatibility rather than selecting solely on price.

Get Crusher Backing Compound in Bangalore

For crusher backing compound requirements in Bangalore, provide the crusher type/model, required quantity and application details to the manufacturer or supplier. This allows the appropriate epoxy grade, mixing ratio, curing system and packaging to be selected for the application.

Terms and Conditions for Supply

1. Payment : 100% With PO

2. Pay :/ NEFT / RTGS / G-pay / CASH

3.Tax : GST-18%

4. Delivery : With in 2 Days FROM PO.

5. Transport : To Pay / Extra As Actuals

6. Stock of Material : Ex Stock @ Mathikere
